In (V) CCC series duplex row angulares contactus pila afferentem est princeps perficientur afferentem disposito resistere simultaneous axial et radiales onerat. Haec afferentem habet duplex row pila consilio, permittens illud ponere stabilitatem et diuturnitatem et cum subiecta superioris onerat. Et unique angulari contactus consilio permittit portantes ad operari normalmente sub tilts onera et apta varietate mechanica apparatu et industriae applications ut electrica Motors, Gearboxes et Pumps. (V) CCC serie gestus solent fabricari a altus-qualitas materiae ad curare bonum gerunt et corrosio resistentia extendendi muneris vitae. Tales Gustas sunt secundum quid facilis ad install et ponere potest amplio altiore perficientur et efficientiam in apparatu.
Parametri producti
| Designatio | Principalem dimensiones (mm) | Basic onus ratings (K) | Basic onus ratings (KGF) | Feligit Celeritas (RPM) | Procul actio | Installation dimensiones (mm) | Pondus | ||||||||
| d | D | B | R (min) | Credoedo | COR | Cr | COR | Uncto | Oleum | A0 (mm) | da (min) | Da (max) | Ra (Max) | (KG) | |
| 5302 | 15 | 42 | 19 | 1 | 17600 | 10200 | 1800 | 1040 | 11000 | 15000 | 22 | 21 | 36 | 1 | 0.11 |
| 5303 | 17 | 47 | 22.2 | 1 | 21000 | 12600 | 2140 | 1280 | 10000 | 13000 | 25 | 23 | 41 | 1 | 0.14 |
| 5304 | 20 | 52 | 22.2 | 1.1 | 24600 | 15000 | 2510 | 1530 | 9000 | 12000 | 26.7 | 27 | 45 | 1 | 0.23 |
| 5305 | 25 | 62 | 25.4 | 1.1 | 32500 | 20700 | 3350 | 2110 | 7500 | 10000 | 31.8 | 32 | 55 | 1 | 0.34 |
| 5306 | 30 | 72 | 30.2 | 1.1 | 40500 | 28100 | 4150 | 2870 | 6300 | 8500 | 36.5 | 37 | 65 | 1 | 0.51 |
| 5307 | 35 | 80 | 34.9 | 1.5 | 51000 | 36000 | 5200 | 3700 | 5600 | 7500 | 41.6 | 44 | 71 | 1.5 | 0.79 |
| 5308 | 40 | 90 | 36.5 | 1.5 | 56500 | 41000 | 5800 | 4200 | 5300 | 6700 | 45.5 | 49 | 81 | 1.5 | 1.05 |
| 5309 | 45 | 100 | 39.7 | 1.5 | 68500 | 51000 | 7000 | 5200 | 4500 | 6000 | 50.6 | 54 | 91 | 1.5 | 1.4 |
| 5310 | 50 | 110 | 44.4 | 2 | 81500 | 61500 | 8300 | 6250 | 4300 | 5600 | 55.6 | 60 | 100 | 2 | 1.95 |
| 5311 | 55 | 120 | 49.2 | 2 | 95000 | 73000 | 9700 | 7450 | 3800 | 5000 | 60.6 | 65 | 110 | 2 | 2.3 |
| 5312 | 60 | 130 | 54 | 2.1 | 125000 | 98500 | 12800 | 10000 | 3400 | 4500 | 69.2 | 72 | 118 | 2 | 3.15 |
| 5313 | 65 | 140 | 58.7 | 2.1 | 142000 | 113000 | 14500 | 11500 | 3200 | 4300 | 72.8 | 77 | 128 | 2 | 3.85 |
| 5314 | 70 | 150 | 63.5 | 2.1 | 159000 | 128000 | 16200 | 13100 | 3000 | 3800 | 78.3 | 82 | 138 | 2 | 4.9 |
