In Qj200 series duplex row angularis contactus pila afferentem est summus praecisione, summus onus-portantes, ut late in mechanica apparatibus, praesertim ubi necesse est ad axial et radiales onerat. Haec series gestus habet duplex row consilio quod praebet altius rigorem et stabilitatem. Atrum contactus structuram efficaciter reduces friction et gerunt per summus celeritate operatio, ita extendens Service vitae. QJ200 series gestus solent ex summus qualis ferro, et superficie specialiter tractari esse corrosio repugnans et altus-temperatus repugnant. Praeterea, in interioribus et exterioribus annulos QJ200 series rationabiliter disposito, faciens illud magis convenient ad install. Ob eius optimum perficientur, haec series in gestus late in automobile, aviation, metallurgy, metalla et alia industrias.
Parametri producti
| Designatio | Principalem dimensiones (mm) | Basic onus ratings (K) | Basic onus ratings (KGF) | Feligit Celeritas (RPM) | Procul actio | Installation dimensiones (mm) | Pondus | ||||||||
| d | D | B | R (min) | Credoedo | COR | Cr | COR | Uncto | Oleum | A0 (mm) | da (min) | Da (max) | Ra (Max) | (KG) | |
| QJ206 | 30 | 62 | 16 | 1 | 31000 | 45000 | 3150 | 4600 | 8500 | 12000 | 32.2 | 36 | 56 | 1 | 0.24 |
| QJ207 | 35 | 72 | 17 | 1.1 | 41000 | 61500 | 4200 | 6250 | 7500 | 10000 | 37.5 | 42 | 65 | 1 | 0.35 |
| Qj208 | 40 | 80 | 18 | 1.1 | 49000 | 77500 | 5000 | 7900 | 6700 | 9000 | 42 | 47 | 73 | 1 | 0.45 |
| Qj209 | 45 | 85 | 19 | 1.1 | 55000 | 88500 | 5600 | 9000 | 6300 | 8500 | 45.5 | 52 | 78 | 1 | 0.52 |
| Q210 | 50 | 90 | 20 | 1.1 | 57000 | 97000 | 5850 | 9900 | 5600 | 8000 | 49 | 57 | 83 | 1 | 0.59 |
| QJ211 | 55 | 100 | 21 | 1.5 | 71000 | 122000 | 7200 | 12500 | 5300 | 7100 | 54.3 | 64 | 91 | 1.5 | 0.77 |
| QJ212 | 60 | 110 | 22 | 1.5 | 85500 | 150000 | 8750 | 15300 | 4800 | 6300 | 59.5 | 69 | 101 | 1.5 | 0.98 |
| QJ213 | 65 | 120 | 23 | 1.5 | 97500 | 179000 | 9950 | 18300 | 4300 | 6000 | 64.8 | 74 | 111 | 1.5 | 1.2 |
| QJ214 | 70 | 125 | 24 | 1.5 | 106000 | 197000 | 10800 | 20100 | 4000 | 5600 | 68.3 | 79 | 116 | 1.5 | 1.3 |
| QJ215 | 75 | 130 | 25 | 1.5 | 110000 | 212000 | 11200 | 21700 | 3800 | 5300 | 71.8 | 84 | 121 | 1.5 | 1.5 |
| QJ216 | 80 | 140 | 26 | 2 | 124000 | 236000 | 12600 | 24100 | 3600 | 5000 | 77 | 90 | 130 | 2 | 1.85 |
| QJ217 | 85 | 150 | 28 | 2 | 143000 | 276000 | 14600 | 28200 | 3400 | 4800 | 82.3 | 95 | 140 | 2 | 2.2 |
| QJ218 | 90 | 160 | 30 | 2 | 164000 | 320000 | 16700 | 32500 | 3200 | 4300 | 87.5 | 100 | 150 | 2 | 2.75 |
| QJ219 | 95 | 170 | 32 | 2.1 | 177000 | 340000 | 18000 | 35000 | 3000 | 4000 | 92.8 | 107 | 158 | 2 | 3.35 |
